C HAPTER 1 M AINTENANCE T ESTS
30 9650-0801-01 Rev. B
13.0 SpO
2
Test
Equipment Fluke Index 2 SpO
2
Simulator (or equivalent), Nellcor™ SPO2 Finger Probe
Test Setup Disconnect any ECG cable or IBP probes from the Propaq MD unit.
Do This... Observe This... Pass/Fail
13.1 Power on the Propaq MD unit without the
SpO
2
sensor attached.
Verify that the SpO
2
numeric
displays INITIALIZING, then
goes blank.
13.2 Connect the SpO
2
sensor to the Propaq MD
unit.
Verify that SpO
2
numeric
displays SEARCHING.
13.3 Set the simulator to 70% SpO
2
and 60 PPM.
Attach the SpO
2
sensor to the simulator.
Verify that after a brief period of
initialization, the
SpO
2
numeric
displays an SpO
2
value between
67% and 73%.
Verify that the displayed pulse
rate reads 60 +/- 3 bpm.
o o
o o
13.4 Set the simulator to 80% SpO
2
and 60 PPM. Verify that after a brief period of
initialization, the
SpO
2
numeric
displays an SpO
2
value between
77% and 83%.
Verify that the displayed pulse
rate reads 60 +/- 3 bpm.
o o
o o
13.5 Set the simulator to 90% SpO
2
and 60 PPM. Verify that after a brief period of
initialization, the
SpO
2
numeric
displays an SpO
2
value between
87% and 93%.
Verify that the displayed pulse
rate reads 60 +/- 3 bpm.
o o
o o
13.6 Disconnect the SpO
2
simulator.
