S1: weight status, ST=standstill, US= not
standstill ,
OL= overload
S2: weight mode, GS=gross weight, NT=net weight
S3: weight value sign,
“+” or ” –“
S4: weight unit sign,
“kg” or “lb”
Data: weight value, including decimal point
CR: carriage return
LF: line feed
3.2.4 I/O connection(option)
1. The indicator I / O card can achieve external control command operation
via an external input 4, and to complete remote control by computer or other
controlling instrument.
2. Output 4 signal through the I / O card and can be connected with
external control equipment for the realize the automatic control function of the
external control or the executive instrument. The indicator can set 4 function
pack, the function of each function pack can output respectively 4 different
signals.
3. input function. Input port and input signals as bellows:
Input port Port definition Function instruction
In1 Zero input port External zero signal input
In2 Tare output port External tare signal input
In3 Print input port External print signal input
In4 Gross/net weight input port External gross and net
weight signal input
