ATO-400P / ATO-600P Operating Procedures
30
7.6 Review Record Procedure
This procedure describes the steps for reviewing a test record residing in the ATO’s working
memory. The user can view the record on the LCD display or print the record on the thermal
printer.
This feature is useful when the user wants to review a test record stored in the ATO’s Flash
EEPROM.
NOTE
To review a test record stored in Flash EEPROM, the user must first restore the test record from
Flash EEPROM to working memory (see paragraph 7.1.9 Restore Record Procedures).
Table 8.0 Review Record Procedure
STEP ACTION ATO DISPLAY
8-1 On the START MENU, press key #2
(SETUP) to select the SETUP MENU (shown
at right).
8-2 Press key#2 (REVIEW RECORD) on the
SETUP MENU, which displays the REVIEW
RECORD menu options.
8-3 If a record’s test results are to be printed,
press key #2 to select the PRINT TEST
RECORD option of the REVIEW RECORD
display. The “PLEASE WAIT
PRINTING… ” notice displays while printing.
When printing is complete, the display returns
to the START MENU. This ends the
procedure for this option of the SETUP menu.
8-4 If records are to be viewed in on the LCD,
press key #1 to select the SCROLL TEST
RECORDS option of the REVIEW RECORD
display. Scroll through the test records by
using the
? and ? keys.
1. ENTER ID
2. REVIEW RECORD
3. RESTORE RECORD
4. NEXT PAGE
REVIEW RECORD
1. SCROLL TEST RECORD
2. PRINT TEST RECORD
PLEASE WAIT
PRINTING . . .
RECORD ID INFO:
1710
VIC
ABC
