ATO-400P / ATO-600P Operating Procedures
23
Table 5.0 Run Test Procedure (Measure an Unknown Resistance Continued)
STEP ACTION ATO DISPLAY
5-12 “RUN ANOTHER TEST?” displays.
5-13 If another test is required; press key #1
(YES). The SELECT TEST CURRENT
menu will appear. Go to step 5-14.
If another test is not required, then press
key #2 (NO) and go to step 5-15.
5-14 Return to step 5-2 to setup for another test
Repeat the sequence from step 5-2 to step
5-12. Step 5-2 thru 5-12 displays repeat.
5-15 “SAVE THIS RECORD?” displays when
another test was not selected in step 5-12.
The test record contains all the readings
taken in this test.
5-16 To save this record, press key #1 (YES). If
the test record is not to be saved, press key
#2 (NO) and go to step 5-18.
NOTE
A test record is saved in Flash
EEPROM. A record number
will be automatically assigned
to the record by the ATO.
(The Test record was assigned
#2 in this example).
5-17 When the record is saved (RECORD
NUMBER “x” shows on the display),
press ENTER to return to the “START
MENU”.
5-18 Pressing key #2 (NO) on SAVE THIS
TEST RECORD (see step 5-15) causes the
ARE YOU SURE? prompt (shown at
right).
ARE YOU SURE?
DATA WILL BE LOST!
1. DO NOT SAVE RECORD
2. SAVE RECORD
1. RUN TEST 04/11/05
2. SETUP 12:24:01
3. DIAGNOSTIC
RECORD NUMBER 2
HAS BEEN SAVED!
SAVE THIS TEST RECORD?
1. YES
2. NO
SELECT TEST CURRENT:
1. 10A 2. 25A 3. 50A
4. 100A 5. 200A 6. 300A
7. 600A 8. CUSTOM
RUN ANOTHER TEST?
1. YES
2. NO
