Anritsu 681XXC - Manual (Page 205)

Table of Contents
7-1 INTRODUCTION . . . . . . . . . . . . . . . . . . . 7-3
7-2 MASTER-SLAVE OPERATION . . . . . . . . . . . 7-4
Connecting the Instruments . . . . . . . . . . . 7-4
Initiating Master-Slave Operation . . . . . . . . 7-5
Master-Slave Operation . . . . . . . . . . . . . 7-7
Master-Slave Operation in VNA Mode . . . . . . 7-7
Terminating Master-Slave Operation . . . . . . . 7-9
7-3 USE WITH A 56100A SCALAR NETWORK
ANALYZER . . . . . . . . . . . . . . . . . . . . . 7-10
Connecting the 681XXC to the 56100A . . . . . 7-10
7-4 USE WITH A 360B VECTOR NETWORK
ANALYZER . . . . . . . . . . . . . . . . . . . . . 7-12
Connecting the 681XXC to the 360B . . . . . . 7-12
Modes of Operation . . . . . . . . . . . . . . . 7-13
Source Lock Mode . . . . . . . . . . . . . . . 7-13
Tracking Mode . . . . . . . . . . . . . . . . . 7-15
7-5 USE WITH A HP8757D SCALAR NETWORK
ANALYZER . . . . . . . . . . . . . . . . . . . . . 7-16
Connecting the 681XXC to the HP8757D . . . . 7-16
Setting Up the 681XXC . . . . . . . . . . . . . 7-17
Initiating HP8757D SNA Operation . . . . . . . 7-19
Chapter 7
Use With Other Instruments
