5-30 681XXC OM
Model 68137C w/Option 15A Serial No. ____________________ Date ___________
Model 68137C with Option 15A High Power
(with Option 2F Step Attenuator)
Power Level Accuracy *
(CW Frequency = 5.0 GHz)
Set Power Measured Power
+ 7 dBm
+ 6 dBm
+ 5 dBm
+ 4 dBm
+ 3 dBm
+ 2 dBm
+ 1 dBm
+ 0 dBm
– 1 dBm
– 2 dBm
– 3 dBm
– 4 dBm
– 5 dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
* Specification is ± 1.0 dB.
Power Level Flatness (Step Sweep)
Set Power Max Power Min Power Variation **
+ 7 dBm _________dBm __________dBm _________dB
** Maximum variation is 1.6 dB.
Power Level Flatness (Analog Sweep)
Set Power Max Power Min Power Variation ***
+ 7 dBm _________dBm __________dBm _________dB
*** Maximum variation is 6.0 dB (typical, not a specification).
Table 5-3. Power Level Accuracy and Flatness Test Record (12 of 27)
OPERATION POWER LEVEL ACCURACY
VERIFICATION AND FLATNESS TESTS
