681XXC OM 5-21
Model 68117C Serial No. ____________________ Date ___________
Model 68117C
(with Option 2E Step Attenuator)
Power Level Accuracy *
(CW Frequency = 1.0 GHz)
Power Level Accuracy *
(CW Frequency = 5.0 GHz)
Set Power Measured Power Set Power Measured Power
+9 dBm
+8 dBm
+7 dBm
+6 dBm
+5 dBm
+4 dBm
+3 dBm
+2 dBm
+1 dBm
0 dBm
–1 dBm
–2 dBm
–3 dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
+9 dBm
+8 dBm
+7 dBm
+6 dBm
+5 dBm
+4 dBm
+3 dBm
+2 dBm
+1 dBm
0 dBm
–1 dBm
–2 dBm
–3 dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
_________dBm
* Specification is
±
1.0 dB. * Specification is
±
1.0 dB.
Power Level Flatness (Step Sweep)
Set Power Max Power Min Power Variation **
+9 dBm _________dBm __________dBm _________dB
** Maximum variation is 4.0 dB (0.01 to 0.05 GHz); 1.6 dB (0.05 to 8.4 GHz).
Power Level Flatness (Analog Sweep)
Set Power Max Power Min Power Variation ***
+9 dBm _________dBm __________dBm _________dB
*** Maximum variation is 7.0 dB (0.01 to 0.05 GHz); 6.0 dB (0.05 to 8.4 GHz)(typical, not a specification).
Table 5-3. Power Level Accuracy and Flatness Test Record (3 of 27)
OPERATION POWER LEVEL ACCURACY
VERIFICATION AND FLATNESS TESTS
