QPHY-DDR2 Software Option

QPHY-DDR2-OM-E Rev

QUALIPHY COMPLIANCE TEST PLATFORM

QualiPHY is LeCroy’s compliance test framework which leads the user through the compliance tests. QualiPHY
displays connection diagrams to ensure tests run properly, automates the oscilloscope setup, and generates
complete, detailed reports.

The QualiPHY software application automates the test and report generation.

Figure 6. Report menu in QualiPHY General Setup
