AP034 Active Differential Probe
36 922261-00 Rev A
Description Minimum Requirements Example Test Equipment
Termination, precision 50 Ω ± 0.05% Teledyne LeCroy TERM-CF01
Termination, BNC 50 Ω through male-female Pomona 4119-50
Calibration Fixture ProBus Extension Cable Teledyne LeCroy PROBUS-CF01
Calibration Fixture AP033/AP034 Calibration Fixture Teledyne LeCroy AP03X-CF01
BNC coaxial cable
(2 Required) male-male BNC, approx. 1 m Pomona 5697-36
BNC T Adapter female-male-female Pomona 3285
Banana Plug Adapter
(2 Required) BNC female to dual male banana plug Pomona 1269
Shorting Plug Two 0.025 in. square pins on 0.100 in.
centers Supplied with AP03X-CF01
Adjustment Tool 0.025 in. square tip Johanson 4192
Low Capacitance
Screwdriver
NOTE: If a Teledyne LeCroy ProBus equipped oscilloscope is not available, you may perform the
adjustment procedure with an alternate oscilloscope that meets the other Minimum Specifications,
and the model ADPPS power supply. The input termination of the oscilloscope must be set at 50
Ω ,
the offset or position must remain at center screen, and the high-frequency adjustments must be
performed with the ADPPS connected directly to the input of the oscilloscope.
