AP034 Active Differential Probe
26 922261-00 Rev A
Table 4, Performance Verification Test Equipment
Description Minimum Requirements Test Equipment Examples
Wide Band Oscilloscope
1
Minimum 1 GHz bandwidth
2 mV to 5 V scale factors ProBus
interface equipped
2% vertical accuracy
Teledyne LeCroy LC584A
Digital Multimeter DC: 0.1% accuracy
AC: 0.2% accuracy to measure 200
mV and 2 V rms @ 1 kHz 5½ digit
resolution
Agilent Technologies 34401A
Fluke 8842A-09
Keithley 2001
Function Generator Sine Wave and Square Wave output
waveforms
20 Vp- p into 1 MΩ
70 Hz to 10 MHz frequency range
Agilent Technologies 33120A
Stanford Research Model DS340
Leader LAG-120B
High Frequency Sine Wave
Generator
50 to 500 MHz and 50 kHz
Output adjustable from 300 mV to2
Vp-p
Agilent Technologies 8648C
Terminator, in-line, BNC 50 Ω ±2% coaxial termination Pomona 4119-50
Terminator, precision, BNC 50 Ω ±0.2% Teledyne LeCroy TERM-CF01
Attenuator, BNC 50 Ω ±2%, ÷10 (20 dB) Pomona 4108-20dB
BNC coaxial cable (2 required) male- male BNC, 50 Ω, 36 in. Pomona 5697-36
Calibration Fixture ProBus Extension Cable Teledyne LeCroy PROBUS-CF01
Calibration Fixture AP033/AP034 Calibration Fixture Teledyne LeCroy AP03x-CF01
Banana Plug adapter BNC female-to-banana plug Pomona 1269
NOTE: 1 If a Teledyne LeCroy ProBus equipped oscilloscope is not available, you may use an
alternate oscilloscope that meets the other minimum specifications listed, and the model ADPPS
power supply, to perform the performance verification procedure. The input termination of the
alternate oscilloscope must be set to 50 Ω and the offset or position must remain at center screen.
