AP034 Active Differential Probe
6
922261-00 Rev A
probe tip depends on proximity to probe cable ground, and is therefore non-reproducible. Teledyne LeCroy
has chosen to use a reproducible method of measurement, rather than obtain a more optimistic
measurement.
Typical Electrical Characteristics
Typical characteristics are parameters with no guaranteed performance. Tests for typical
characteristics are not provided in the Performance Verification Procedure.
Bandwidth, probe only (-3 dB):
DC to 1 GHz
Output Zero:
< 3 mV within 30 minutes of autobalance
Residual Autobalance Offset:
≤ 100 μV referred to input with X1 effective gain
Differential Offset Range:
≥1.6 V (÷1 Attenuation)
≥ 16 V (÷10 Attenuation)
≥ 42 V (÷20 Attenuation)
CMRR:
Input Resistance (each side to Ground):
1 M_
Input Capacitance (between inputs):
< 0.85 pF (See Figure 2.)
Input Capacitance (each side to Ground):
< 1.5 pF (See Figure 2.)
Noise (referred to input, 10 to 1000 MHz):
35 nV/√Hz (÷1 Attenuation)
350 nV/√Hz (÷10 Attenuation)
700 nV/√Hz (÷20 Attenuation)
Output Impedance:
50 Ω nominal intended to drive 50 Ω
Harmonic Distortion (3rd order distortion):
–60 dB below fundamental (200 mVp-p output at 100 MHz)
(3rd order intercept):
+20 dBm (at 100 MHz at output)
AC Coupling LF Cutoff (-3 dB):
16 Hz (using plug-on AC Coupler)
