Operator’s Manual
922261-00 Rev A 35
Test Equipment Required
The table on the next page lists the test equipment and accessories, or their equivalents, that are
required for complete calibration. Specifications given for the test equipment are the minimum
necessary for accurate calibration. All test equipment is assumed to be correctly calibrated and
operating within the specifications listed. Detailed operating instructions for the test equipment
are not given in this procedure. Refer to the test equipment manual if more information is needed.
If alternate test equipment is substituted, control settings or calibration equipment setups may
need to be altered. Alternate models of test equipment may have different connector styles
requiring adapters not included in the equipment list.
Table 5, Adjustment Test Equipment
Description Minimum Requirements Example Test Equipment
Wide Band Oscilloscope * 500 MHz bandwidth
2 mV to 200 mV vertical scale factors
ProBus interface equipped* 2%
vertical accuracy
Teledyne LeCroy LT342
Teledyne LeCroy LC344A
Digital Multimeter 0.1% DC volts accuracy at 0.4 V 0.2%
AC volts accuracy at 2 V and 1 kHz
5½ digit resolution
0.01 mV AC volts resolution
Agilent Technologies 34401A
Fluke 8842A-09
Keithley 2001 with test leads
Function Generator Sine and square wave output
20 Vp- p into 1 MΩ
50 Hz to 1 MHz frequency Range
Sync. or Freq. Reference output
Agilent Technologies 33120A
Stanford Research Model DS340
Leader LAG-120B
Fast Rise Pulse Generator Risetime <2 ns
Amplitude >400 mV into 50 Ω
Over/Undershoot <6%
Calibrator signal from Teledyne
LeCroy oscilloscope
Tegam / Tektronix PG506 with
power unit
Sine Wave Generator Output 250 MHz at 1 V RMS Agilent Technologies 8648C, with
male N to female BNC
adapter for the output connector.
Tegam SG504 with TM series
mainframe.
DC Voltage Source 0 to 2 VDC regulated output, settable
to 1 mV resolution HP 6633A
