LSIB-1 Host Interfaces
30 LSIB-OM-E Rev C
On Your Oscilloscope
3. Set up the oscilloscope for LSIB Export mode by
accessing File → Save Waveform.
4. Click the LSIB Export tab on the lower part of the
screen and select the data stream that was used
for your performance test.
Data Stream 1 is selected in the following example.
NOTE: You should see the word "connected" to the
right of the selected data stream (as shown
above). If not, you may need to increase the
Timeout value on the host machine. Be aware that
the acquisition memory settings affect data
transfer rate.
W INDOWS
