Operator's Manual

LSIB-OM-E Rev C

5

LSIB-HOSTCARD Description,
Unpacking, and Installation

Description

LSIB-HOSTCARD is a PCIe x1 ExpressCard/34 adapter

that adds high-speed PCI Express (PCIe) expansion

capability to your laptop. The PCIe cable port provides
PCIe x1 connectivity to oscilloscopes configured with the

LSIB-1 option.

Unpacking

1.

If the carton is damaged upon receipt:

Request the carrier's agent be present when

unpacking and inspecting the contents.

If the contents appear damaged, contact your

local Teledyne LeCroy Corporation representative

to obtain a Return Materials Authorization (RMA)

number and further shipping instructions for any
repair and/or replacement needs.

If all is well, proceed to unpack the carton.
