Appendix C: NFPA Standard-Specific Requirements NFPA 72 Remote Station Fire Alarm System
40 The PDRP-1002 PN 51135:A 03/11/99
NFPA 72 Remote Station Fire Alarm System
Intended for connection to a polarity reversal circuit of a remote station receiving unit
having compatible ratings. All connections are power limited and supervised with the
exception of the reverse polarity loop. Supervision of the loop is the responsibility of
the receiver.
Figure 16 NFPA 72 Remote Station Fire Alarm System
