Appendix C: NFPA Standard-Specific Requirements
NFPA 72 Signaling Systems for Central Station Service
38
The PDRP-1002 PN 51135:A 03/11/99
Using the MS-5012 as a DACT
1)
Reference the MS-5012 manual for additional information.
2)
Program the MS-5012 for slave applications.
3)
The PDRP-1002/PDRP-1002E is not suitable for transmission of a supervisory
signal to the DACT.
Figure 14 Using the MS-5012 as a DACT
TB2
TB3
ALARM
AC POWER
TROUBLE
SUPERVISORY
1
2
3
4
5
6
7
8
9
F
E
D
C
A
O
B
1st
EVENT
ENTER
STORE
J2
J3
T B 3
AC Wiring for DACT/FACP must be
connected to the same circuit.
Motherboard
MS-5012
Alarm
TB3-1
TB2-2
TB3-3
TB2-1
Trouble
TB3-4
TB2-4
TB3-6
TB2-3
Red
Black
Yellow
Yellow
Black
White
Green
Ground
Neutral
HOT
120 VAC
12VDC
Battery
2-7AH
Trouble
Alarm
Primary
Phone Line
Secondary
Phone Line
Modular Cable
P/N MCBL-6
MS
50
12X2.
CDR
MS-5012
PDRP-1002/PDRP-1002E
1 2 3 4 5 6
