6
6. SPECIFICATIONS
120425-1244
MOUNTING
EE-IR-RCVR-TABLE TABLE TOP
EE-IR-RCVR-SURFACE SURFACE MOUNT
POWER +12VDC @ 25MA
MAXIMUM RECOMMENDED
CABLE LENGTH 1000 FEET USING CAT-5
CARRIER FREQUENCY
ACCEPTABLE RANGE 25KHZ TO 90KHZ
CONTROL RANGE UP TO 40 FEET DEPENDING ON
REMOTE STRENGTH AND AMBIENT
NOISE CONDITIONS
DIMENSIONS
EE-IR-RCVR-TABLE 0.88” (22.35MM) H
X 3” (76.2MM) W
X 1.375” (34.93MM) D
EE-IR-RCVR-SURFACE 0.67” (17.02MM) H
X 2.5” (63.5MM) W
X 0.32” (8.13MM) D
CONTROL ANGLE 0+/- 30° OFF AXIS
