B-220-HDSPLTR-1x4 Owner’s Manual

B-220-HDSPLTR-1x4 Owner’s Manual

SPECIFICATIONS

DIPSWITCH SETTINGS

Video Support

VESA: 640x480, 800x600, 1024x768, 1280x1024,

1600x1200, 1920x1200

HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p

Video Bandwidth

6.75 Gbps

Video Transmission

Full 1080p HD with 36 bit Deep Color

Audio Support

Surround Sound (up to 7.1ch) DTS-HD Master

Audio and TrueHD high bitrate audio

ESD Protection

Human Body (air gap): 15kV

Human Body (contact): 8kV

HDMI Connector Type

Type A (19 pin female)

Power Supply

5V DC, 1A

Power Consumption

3.5 Watts (max)

Dimensions

6.24” W x 1.01” H x 3.2” D

Weight

1.88lbs (0.86kg)

Certifications & Compliance

Power Supply: CE, FCC, UL, Rohs

Product: CE, FCC, Rohs

EDID

Resolution

Color Depth

Audio

Switch Settings

Auto

First Output

1

1080i@60Hz

24-Bit

7.1ch

2

1080i@60Hz

24-Bit

2ch

3

1080p@60Hz

24-Bit

7.1ch

4

1080p@60Hz

24-Bit

2ch

5

1080p@60Hz

24-Bit 3D

7.1ch

6

1080p@60Hz

24-Bit 3D

2ch

1

2

3

Down Down Down

1

2

3

Up

Up Down

1

2

3

Up Down Down

1

2

3

Down Up

Up

1

2

3

Down Down Up

1

2

3

Down Up Down

1

2

3

Up Down Up

1

2

3

Up

Up Up

Pg. 8

WARRANTY

CONTACTING TECHNICAL SUPPORT

2-Year Limited Warranty
This Binary™ Product has a 2 Year Limited Warranty. This warranty includes parts and

labor repairs on all components found to be defective in material or workmanship

under normal conditions of use. This warranty shall not apply to products which have

been abused, modified or disassembled. Products to be repaired under this warranty

must be returned to SnapAV or a designated service center with prior notification

and an assignment return authorization number (RA).

Phone: (866) 838-5052
Email: [email protected]

120731-0910
