Getting Started
XT85
User Manual
Janam Technologies LLC
2
―4
Charging the Battery
(continued)
Charging the XT Series Device with a Janam Cradle Kit:
1. Insert the mini-barrel plug
of the power
supply into the cradle’s mating receptacle.
2. Plug the female end of the AC line cord
into 2-pin receptacle
on the (brick style)
power supply.
3. Plug in the power supply. Use only easily
accessible wall outlets that are well within
reach of the length of supplied power
cable.
4. Place the XT Series device in the cradle.
The device’s indicator LED will illuminate to
confirm that the device has seated properly
and charging connection has been made.
For charging times and more, refer to Battery Charging and Power Alert Information chart
on Page 11 of this chapter.
Additional Charging Options
To charge a battery in the Cradle’s spare battery well, insert the battery into the well top-down (the
battery contacts should face downward into the back of the cradle) and press down gently. The LED
light on the cradle will illuminate to confirm the charging connection (yellow indicates charging, green
indicates fully charged and red indicates a fault condition).
Removing the battery:
1. Slide the battery lock switch to the unlocked
position (fully to the right).
2. Use the finger lift groove to lift the battery
outward.
Note:
To ensure that user data is
retained it is recommended that XT
Series device have a fully charged
backup battery and operation be
suspended before removing the
main battery. To suspend
operation, press and release the
red Power button
once.
With the main battery removed, the internal backup battery can (when fully
charged) maintain user data for approximately 15 minutes. Allow 1.5 hours for a
fully charged main battery to charge the internal backup battery completely.
For charging times and more, refer to XT Series Device Battery Charging and
Power Alert Information chart on Page 11 of this chapter.
Finger lift groove
Slide to right to unlock
