6 Multi-Command
12-44 WindO/I-NV2 User’s Manual
■ Source Data
Select the data handled by the operation selected for Action Mode.
■ Destination Device
*1 Advanced mode only
Value: Use a constant.
Only a Value can be handled if Action Mode is set to Set or Set ON & OFF Data.
If Action Mode is set to Set ON & OFF Data, the value in the ON Data is written when the trigger
condition is satisfied, and the value in the OFF Data when the trigger condition is no longer satisfied.
Hexadecimal: Select this check box to enter the ON Data and OFF Data values as a
hexadecimal.
Device: Use a word device.
Specify the device.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-67.
Use Reference Device
*1 : Select this check box and specify a device to change the source word device
according to the value of the specified device.
This setting is enabled only if Action Mode is set to Move.
For details, refer to Chapter 2 “Indirect Read and Indirect Write Settings” on
page 2-5.
Transfer *1 : Specify the number of word devices (1 to 64) to transfer.
This setting is enabled only if Action Mode is set to Move.
For details, refer to “Transfer*1” on page 12-14.
Destination Device: Specify the destination word device.
Click to display the Device Address Settings dialog box. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-67.
Use Reference Device *1 : Select this check box and specify a device to change the destination word device
according to the value of the specified device.
This setting is enabled only if Action Mode is set to Move.
For details, refer to Chapter 2 “Indirect Read and Indirect Write Settings” on page 2-5.
Write *1 : Specify the number of word devices (1 to 64) at the destination.
For Move, specify how many times to write.
This setting is enabled only if Action Mode is set to Set, Move, or Set ON & OFF Data.
For details, refer to “Write*1” on page 12-14.
