WindO/I-NV2 User’s Manual 10-25
2 Character Input
10
Data Displa
ys
2.2 Character Input Configuration Procedure
This section describes the configuration procedure for Character Inputs.
1 On the Home tab, in the Parts group, click Data Displays, and then click Character Input.
2 Click a point on the edit screen where you wish to place the Character Input.
3 Double-click the dropped Character Input and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
To switch to Advanced mode, click Advanced.
