2 USB Flash Drives
30-26 WindO/I-NV2 User’s Manual
2.3 Overview of the USB Autorun Function
The USB Autorun function automatically displays a menu screen from which the user can execute predefined
commands when a USB flash drive is inserted into the MICRO/I.
The commands that can be executed with the USB Autorun function are as follows.
●
Downloading a project file
Downloads a project file (ZNV format) saved on a USB flash drive or an SD memory card to the MICRO/I.
When the download is complete, the MICRO/I will reset and start running from the beginning of the project that was
just downloaded.
HG3G HG2G-5F HG4G
USB Autorun Function Menu Screen
USB flash drive
Production line A - replace
display program Copy display program to USB
flash drive
Replace sound data Copy PLC program to USB
flash drive
Production line A - replace
PLC program
Run All Cancel
Confirmation
Press the command to execute. USB Autorun
definition file
(hgauto.ini)
MICRO/I
• This allows operators to change project files and PLC programs without using a computer.
• These defined processes are called commands, and the file that contains the details of the command and
menu screen is called the USB Autorun definition file (hgauto.ini).
• A USB Autorun definition file (hgauto.ini) must be stored on the USB flash drive to use the USB Autorun
function.
• An SD memory card can be used as the destination for saving project files (ZNV format) , PLC program
files (ZLD format), and for copying files.
HG3G HG2G-5F HG4G
Save
Save
Download
Computer
SD Memory
Card
USB flash drive
MICRO/I
USB Autorun
definition file
(hgauto.ini)
Project file
(ZNV format)
Project file
(ZNV format)
Refer to Chapter 28 “1 Project Transfer Function” on page 28-1 for important notes and limitations.
