3 Project Settings Dialog Box
4-26 WindO/I-NV2 User’s Manual
This section describes items and buttons on the Project Settings dialog box.
3.1 System Tab
The System tab is used to configure MICRO/I operations for the project data overall.
■ Screen No. Format
Selects the type of data to use for the System Area 1 Display screen number (address+0) as BCD or BIN.
■ Start Time (sec)
Specifies the time from when the MICRO/I power is turned on until communications start with the host (0 to 9999
seconds).
3 Project Settings Dialog Box
HG3G HG2G-5F HG2G-5S HG2G-S HG4G HG1F HG2F HG2S HG3F HG4F
HG3G HG2G-5F HG2G-5S HG2G-S HG4G HG1F HG2F HG2S HG3F HG4F
Default Screen: Specifies the screen number of the base screen to display first when the MICRO/I is turned on (0 to
3000). When 0 is specified, the MICRO/I is in the screen waiting state. Write a screen number to
System Area 1 Display screen number (address+0) or specify the default screen number from 1 to
3000.
