Underhung Geared End Trucks (Refer to Fig. 2-1)
Max.
Cap.
(Tons)
Max.
Span
(ft)
End Truck
Model #
Wheel
Dia.
(in)
Flange
Range
Std. (in)
A
Overall
Length
(in)
B
Roller
Base
(in)
D
Wheel
Base
(in)
E *
Beam
Beyond
Span
(in)
J
Hand
Wheel
Offset
(in)
M
End
Truck
Frame
Width
(in)
U **
Wheel
Bottom
to
Beam
Top
(in)
X Width
Beyond
Span (in)
Y
Wheel
Running
Surface
to
Upper
Most
Part of
ET
(in)
End
Truck
Weigh
t
(lbs/pr
)
2 35 UG-3-0235 4.33 3 - 6 60 53 39 12 T/2+9.0 T+8.1 1.8 11.3-T/2 6.5 503
2 45 UG-3-0245 4.33 3 - 6 82 75 61 12 T/2+9.0 T+8.1 1.8 11.3-T/2 6.5 640
3 35 UG-3-0335 4.92 3 - 6 60 53 35 12 T/2+8.9 T+8.2 1.9 11.3-T/2 6.7 529
3 45 UG-3-0345 4.92 3 - 6 82 75 57 12 T/2+8.9 T+8.2 1.9 11.3-T/2 6.7 666
5 35 UG-3-0535 5.51 4 - 6 60 53 33 12 T/2+9.0 T+9.8 2.0 11.3-T/2 6.8 611
5 45 UG-3-0545 5.51 4 - 6 82 75 55 12 T/2+9.0 T+9.8 2.0 11.3-T/2 6.8 768
* minimum overhang is M/2
** includes 3/8" thick beam mounting plates
