Harrington Hoists and Cranes Series 3 End Truck - Manual (Page 73)

Applicable End Truck Gear Motor Model - G1J075 & G1J150
Fig.
No.
Part Name
Qty.
Per
Motor
Applicable End Truck
1 Hp
40 and 80 FPM
2 Hp
120 FPM
1/0.6 Hp
80/20 FPM
1 Pinion 1 N6GJ075301
2 Ball Bearing 2 90007-06 (6306-ZZ)
3 Gear Box “A” 1 N6GJ075303
4 Snap Ring 1 90472-100
5 Collar “A” 1 N6GJ075305
6 Collar “B” 1 N6GJ075306
7 Gear 4
*G1 Motor
Version
1
40 FPM
N6GJ075411L
N6GJ075411H N6GJ075411L
*G1 Motor
Version
80 FPM
N6GJ075411S
*G1D Motor
Version
80 FPM
N6GJ075954S
N6GJ150954H
8 Snap Ring 1 90471-30
9 Gear Box Packing 1 N6GJ075310
10 Gear Box “B” 1 N6GJ075401
11 Gear 2
*G1 Motor
Version
1
40 FPM
N6GJ075307L
N6GJ075307H N6GJ075307L
*G1 Motor
Version
80 FPM
N6GJ075307S
*G1D Motor
Version
80 FPM
N6GJ075921S
N6GJ150921H
12 Ball Bearing 2 90006-03 (6203-ZZ)
13 Stator Assembly 1 N6GJ0755501S N6GJ1505501T N6GJ0755501B
14
Rotor
Assembly
*G1 Motor
Version
1
40 & 80 FPM
N6GJ0755502S
N6GJ1505502T N6GJ0755502B
*G1D Motor
Version
80 FPM
N6GJ0755911S
N6GJ1505911T
15
Ball
Bearing
G1 Motor
Version
1
40 & 80 FPM
90010-04
90011-05
90010-04
G1D Motor
Version
80 FPM
90009-05
90010-06
* The Model number on the motor data nameplate can identify the motor version as G1 or G1D.
S
ect
io
n
1
0 R
ep
lacem
en
t P
ar
ts
10.
4
E
le
ct
ri
c
G
ear
M
o
to
rs
73
