Max-E-Lift Underhung Geared End Trucks (Refer to Fig. 2-1)
Max.
Cap.
(Tons)
Max.
Span
(ft)
End Truck
Model #
Wheel
Diame
ter (in)
Flange
Range
Std. (in)
A
Overal
l
Length
(in)
B
Roller
Base
(in)
D
Wheel
Base
(in)
E *
Beam
Beyond
Span
(in)
J
Hand
Wheel
Offset
(in)
M
End
Truck
Frame
Width
(in)
U **
Wheel
Botto
m to
Beam
Top
(in)
X
Width
Beyond
Span
(in)
Y
Wheel
Running
Surface
to Upper
Most
Part of
ET
(in)
End
Truck
Weight
(lbs/pr)
2
35
MUG-3-0235
4.33
3 - 6
87
80
66
12
T/2+9.0 T+8.1
1.8
11.3-T/2
6.5
671
2
45
MUG-3-0245
4.33
3 – 6
99
92
78
12
T/2+9.0 T+8.1
1.8
11.3-T/2
6.5
746
3
35
MUG-3-0335
4.92
3 – 6
91
84
66
12
T/2+8.9 T+8.2
1.9
11.3-T/2
6.7
722
3
45
MUG-3-0345
4.92
3 – 6
103
96
78
12
T/2+8.9 T+8.2
1.9
11.3-T/2
6.7
797
5
35
MUG-3-0535
5.51
4 - 6
95
88
68
12
T/2+9.0 T+9.8
2.0
11.3-T/2
6.8
861
5
45
MUG-3-0545
5.51
4 - 6
107
100
80
12
T/2+9.0 T+9.8
2.0
11.3-T/2
6.8
946
