Harrington Hoists and Cranes Series 3 End Truck User Manual
Page 70
Fig.
No.
Part Name
Qty.
Per
Motor
Applicable End Truck
0.33 Hp
40 and 80 FPM
0.5 Hp
120 FPM
0.33/0.1 Hp
80/20 FPM
0.5 Hp
40 and 80 FPM
1 Hp
120 FPM
0.5/0.13 Hp
80/20 FPM
21
Brake Bracket
1
N6GJ025609
N6GJ040609
N6GJ075609
N6GJ040609
22
Terminal Cover
1
N6GJ3025701S
N6GJ025701B
N6GJ040701S
23
Cable Holder
1
62587
24
Cable Packing
1
62588
25
Terminal Cover Packing
1
N6GJ025707S
N6GJ025707B
N6GJ040707S
26
Bolt
[x]
90912-54
(M6x40) [8]
90912-54 (M6x40) [4]
90912-56 (M6x50) [4]
27
Spring Washer
[x]
90127-09 (M6)
[12]
90127-09 (M6)
[16]
90127-09 (M6) [12]
28
Snap Ring
1
90471-15
90471-20
90471-15
29
Screw w/ Spring Washer
4
MS555010
30
Screw w/ Spring Washer
[x]
MS555010 (M4) [2]
MS555010 (M4)
[4]
MS555010 (M4) [2]
MS555010 (M4)
[4]
31
Ball Bearing
G1 Version
1
90010-04
40 & 80 FPM
90009-05
90010-04
90009-05
90010-04
G1D Version
90009-05
80 FPM
90010-04
32
Bolt
[x]
90912-50
(M6x20) [4]
90912-50
(M6x20) [12]
90912-50
(M6x20) [12]
90912-50 (M6x20) [8]
90912-50
(M6x20) [8]
33
Spring Pin
2
91481-112 (M8x10)
34
Spring Pin
2
91481-97 (M6x12)
35
Bolt
8
90912-73 (M8x25)
36
Spring Washer
4
90127-11 (M8)
37
Bolt
4
UMX-0235 TO 0350 90933-29 (M8X30)
TMX-0135 TO 0535 90933-30 (M8X35)
UMX 0535 TP 0550 90933-29 (M8X30)
TMX-0560 90933-30 (M8X35)
38
Screw
3
97985-26 (M4X25)
40
7P Terminal Strip
[x]
N6GJ025B98051 [1]
E6F606003 [2]
N6GJ025B98051 [1]
E6F606003 [2]
