Harrington Hoists and Cranes Series 3 End Truck - Manual (Page 77)

Applicable End Truck Models: UG-3-03xx, TG-3-01xx, & TG-3-0535
Fig.
No.
Drawing/
Part No.
Name
Qty. Parts
per Pair of
End Trucks Notes
113A N6GO310V5303 Gear Head Assembly 2
114 N6GO310V301 Pinion Axle “G” 2
115 N6GO310306 Collar 2
116 N6GO310303 Axle Holder 2
117 90472-42 Snap Ring 2
118 90471-20
Snap Ring
2
119 90005-04
Ball Bearing
4 6004-ZZ
153
90933-27
Bolt 8
M8x20 UG-03XX
90933-28 M8x25 TG-01xx
thru 0535
154 90127-11 Spring Washer 8 M8
Applicable End Truck Models: UG-3-05xx & TG-3-0550
Fig.
No.
Drawing/
Part No.
Name
Qty. Parts
per Pair of
End Trucks
Notes
113A N6GO4505303 Gear Head Assembly 2
114 N6GO450301
Pinion Axle “G”
2
115 N6GO310306 Collar 2
116 N6GO310303 Axle Holder 2
117 90472-42 Snap Ring 2
118 90471-20 Snap Ring 2
119 90005-04
Ball Bearing
4 6004-ZZ
153 90933-27
Bolt
8 M8x20
154 90127-11 Spring Washer 8 M8
77
