Hand W heel and Drive Shaft Assembly Par ts List
Fig.
Drawing Number
Name
Qty. Per Pair of End Trucks
Kit A
Kit B
Kit C
Kit D
1
N6GK2105011
Hand Wheel Assembly
1
1
1
1
2
N6GK210510
Hand Wheel
1
1
1
1
3
90471-52
Snap Ring
1
1
1
1
4
N6GK2105504
Guide Plate Assembly
1
1
1
1
5
N6GK210504
Guide Plate
1
1
1
1
6
T3GO10129
Hand Chain Guide
2
2
2
2
7
90934-24
Nut (M8x1.25)
4
4
4
4
8
90127-11
Spring Washer (M8)
4
4
4
4
9
90912-73
Socket Bolt (M8x25)
4
4
4
4
10
N6GK210523
Connecting Shaft
2
2
2
2
11
N6GK310521
Joint Shaft
--
1
2
3
12
N6GK210525
Bolt “A”
1
3
5
7
13
N6GK210526
Bolt “B”
1
1
1
1
14
90935-07
Slotted Nut (M10x1.5)
2
4
6
8
15
90094-14
Split Pin (2x18)
2
4
6
8
16
62492
Bearing Support Assembly
--
1
2
3
17
62492-1
Bearing Support Bracket Assy.
--
1
2
3
18
90115-02
Pillow Block
--
1
2
3
19
90931-89
Bolt (M16x50)
--
2
4
6
20
90934-39
Nut (M16x2.0)
--
2
4
6
21
90125-17
Washer (M16)
--
2
4
6
22
90127-15
Spring Washer (M16)
--
2
4
6
23
90934-45
Nut (M20x2.5)
--
3
6
9
24*
62490-1
Horizontal Support Bracket A
--
1
2
3
62490-2
Horizontal Support Bracket B
--
1
2
3
62490-3
Horizontal Support Bracket C
--
1
2
3
62490-4
Horizontal Support Bracket D
--
1
2
3
25**
62491-1
Vertical Support Bracket Assy E
--
1
2
3
62491-2
Vertical Support Bracket Assy F
--
1
2
3
26
90931-45
Bolt (M12x40)
--
4
8
12
