Harrington Hoists and Cranes Series 3 End Truck - Manual (Page 55)

Applicable End Truck Models - UP-3-0135 to 0535
Applicable End Truck
Figure
No.
Part Name
Quantity
Per Pair
UP-3-0235 to 0245
UP-3-0335 UP-3-0535
4 Track Wheel “B” Assembly 8 62345-01 62345-02 62345-03
2 Ball Bearing 16 90006-06 (6206-ZZ) 90005-07 (6007-ZZ) 90005-08 (6008-ZZ)
3 Snap Ring 8 90472-62 90472-62 90472-68
5 Washer 8 62324-01 62324-02 62324-03
6 Snap Ring 8 90471-30 90471-35 90471-40
7 Guide Roller Assembly 8 N6QO3101108
8 Ball Bearing 8 90006-05 (6205-ZZ)
9 Snap Ring 8 90472-52
10 Washer 8 62324-04
11 Snap Ring 8 90471-25
12 Tapered Washer 16 90434-18 (M16x5 ) 90434-22 (M20x5 )
13 Nut 32 90934-39 (M16x2.0) 90934-45 (M20x2.5)
14 Tapered Washer 8 90435-18 (M16x9 ) 90435-22 (M20x9 )
15 Bolt 8 90933-124 (M16x90) 90933-168 (M20x100)
16 Bolt 8 90931-92 (M16x65) 90933-135 (M20x75)
17 Bolt 8 90931-46 (M12x45)
18 Washer 8 90125-15 (M12)
19 Nut 16 90934-33 (M12x1.75)
20 Bolt 4 90931-01 (M8x35)
21 Washer 4 90125-14 (M10)
22 Nut 8 90934-24 (M8x1.25)
23 Buffer 4 N6QL210207
24 End Bracket “A” 2 62346-01
25 End Bracket “B” 2 62346-02
