Figure 2-5, Figure 2-6 – Harrington Hoists and Cranes Series 3 End Truck User Manual
Page 19
BRIDGE CONTROL BOX
GUIDE WIRE
MOTOR
BRACES
BRIDGE BEAM
END TRUCK
F
SPAN
TYPICAL CRANE SYSTEM WITH TOP RUNNING MOTORIZED END TRUCK
GUIDE ROLLERS
BUMPER
TROLLEY STOP
RUNWAY RAIL
RAIL SUPPORT STRUCTURE
Figure 2-5
BRACES
F
BRIDGE BEAM
END TRUCK
SPAN
FOR DRIVE SHAFT
SUPPORT ASSEMBLIES
DRIVE SHAFT
HAND WHEEL
GUIDE WIRE
TYPICAL CRANE SYSTEM WITH TOP RUNNING GEARED END TRUCK
GUIDE ROLLERS
BUMPER
TROLLEY STOP
RAIL SUPPORT STRUCTURE
RUNWAY RAIL
HAND CHAIN
TYPICAL HOIST & TROLLEY
Figure 2-6
19
