Harrington Hoists and Cranes ER Large Capaciy Hoist - (ER1) - Manual (Page 49)

49
10.13 Hook Type Control Station and Cable Parts
Figure
No.
Part Name
Parts Per
Hoist
100S 150S 200S
1 Switch Box 1 MR1IS9401
2 Switch Box Lid 1 MR1DS9411
3 Switch Box Packing 1 MR1DS9421
4 Machine Screw with Spring Washer 4 MS551010
5 Spacer 4 MS517010
6 Plate 1 MR1HS9405
7 Machine Screw with Spring Washer 2 E6F151003
8 Cord Holder Support Packing 1 MS527010
9 Cord Cover 1 ER1IS9347
10 Machine Screw with Spring Washer 4 MS554010
S 1 MR1IS5445
11 Plate Assembly
D 1 ER1IB5445
12 Machine Screw with Spring Washer 4 MS554010
13 Machine Screw with Spring Washer 4 MS555010
14 Electromagnetic Contactor 1 MGC22306A
15 Machine Screw with Spring Washer 2 MS556010
16 Machine Screw with Spring Washer 3 MS555010
Transformer
-
Primary = 208-230/460V
- Secondary =110V
1 TRF62M601
17
Transformer
-
Primary = 575V
- Secondary =110V
1 TRF33K601
17A
Fuse
- Trans. Secondary =110V
1 9006272
18
Electromagnetic Contactor (DUAL SPEED
ONLY)
D 1 MGC11226A
19 Machine Screw with Spring Washer D 2 J1AW24001414
20 Terminal Plate 18p 1 ECP1518AA
21 Machine Screw with Spring Washer 2 J1AW24001010
22 Machine Screw with Spring Washer 4 MS554010
23 Spring Lock Washer 4 9012711
24 Socket Bolt 4 9091272
25 Holder Cover 1 ECP5924AE
26 Cord Packing 2 ECP5924AC
27 Holder Nut 1 ECP5924AD
28 Power Supply Cable 4C Assembly 1 MR1JS1771
29 Cord Holder Packing 1 ECP6922AA
30 Cable Support 14 1 M7HE010M1105
31 Power Supply Cable 4C 1 8/4
32 Cable Support Arm 1 ER1IS9431
33 Cable Holder A Assembly 1 60704
34 Cable 4C Complete Set 2 MR1IS1751 MR1JS1751
35 Cable Packing 2 ECP6916AA
36 Cord Holder A Assembly 2 60704
37 Power Supply Cable 4C 2 12/4
38 Plug 4P 2 ECP2304AA
Cable 3C Complete Set S 2 MR1IS1761 MR1JS1761
39
Cable 4C Complete Set D 2 ER1IB1761 ER1JB1761
Cable Packing for 3C S 2 ECP6918AA
40
Cable Packing for 4C D 2 ECP6914AA
41 Cord Holder A Assembly 2 60704
S. O. Cord 3C S 2 16/3
42
S. O. Cord 4C D 2 16/4P
43 Plug 5P 2 E3S613003
