Table 5-5

Chain Wear Dimensions

“P” Dimension

inch (mm)

“d” Dimension

inch (mm)

Capacity Code

Standard

Discard

Standard

Discard

080S, 100L, 100S,
150S, 200S

6.75 (171.5)

6.85 (174.1)

0.44 (11.2)

0.40 (10.1)

Table 5-6

Motor Brake Wear Dimensions

NOTICE

Brake must be properly adjusted before measuring "A".

See

Section 6.3

of EROM

"A" Dimension - inch (mm)

Single Speed

Dual Speed

Capacity Code

Standard

Discard

Standard

Discard

080S, 100L, 100S, 150S, 200S

0.83 (21)

0.77 (19.5)

1.54 (39)

1.48 (37.5)
