35
10.6 Electric Parts
Figure
No.
Part Name
Parts Per
Hoist
080S 100L
Parts Per
Hoist
100S 150S 200S
1 Limit Switch Assembly 1 ER1ES2551 2 ER1ES2551
2 Spring Washer 3 9012709 6 9012709
3 Socket Bolt 3 9091247 6 9091247
S 1 S 2
4 Terminal Plate 6P
D 2
ECP1306AA
D 4
ECP1306AA
S 2 S 4
5 Machine Screw with Spring Washer
D 4
MS556010
D 8
MS556010
6 Plate 1 ER1EB9441 2 ER1EB9441
7 Plate Screw 4 ER1BS9445 8 ER1BS9445
8 Hinge 1 ER1ES9442 2 ER1ES9442
9 Machine Screw with Spring Washer 2 E6F151003 4 E6F151003
10 Pan Head Machine Screw 2 ER1BS9443 4 ER1BS9443
11 Machine Screw with Spring Washer 2 MS554010 4 MS554010
12 Electromagnetic Contactor 1 MGC23306B 2 MGC23306B
13 Machine Screw with Spring Washer 4 MS555010 8 MS555010
Transformer 230/460V 1 TRF63M601 2 TRF63M601
14
Transformer 575V 1 TRF33K601 2 TRF33K601
14a Fuse – Secondary 110V 1 9006272 2 9006272
15 Machine Screw with Spring Washer 4 MS555010 8 MS555010
16 Terminal Plate 3P 1 ECP1303AA 2 ECP1303AA
17 Machine Screw with Spring Washer 2 MS555010 4 MS555010
18 Terminal Cover Packing 1 ER1BS9512 2 ER1BS9512
19 Socket Holder 1 ER1BS9511 2 ER1BS9511
20 Machine Screw with Spring Washer 4 ES656003 8 ES656003
21 Socket 4P Assembly 1 ER1ES1523 2 ER1ES1523
22 Tapping Flat Head Machine Screw 8 ES558003 16 ES558003
S 1 ER1ES1564 S 2 ER1ES1564
23
Socket 5P Assembly (Single
Speed)
D 1 ER1EB1564 D 2 ER1EB1564
Power Supply Cable Assembly
(Manual Trolley ONLY)
1 ER1HS1771G
24
Power Supply Cable Assembly
(Hook & Lug Mount ONLY)
1 ER1HS1771
25 Plug 4P 1 ECP2304AA
26
Electromagnetic Contactor
- High Speed
D 1 MGC13226B D 2 MGC13226B
27 Machine Screw with Spring Washer D 2 MS556010 D 4 MS556010
28
CH Meter
- Trans. Secondary = 110V
1 ECP91CHAB 2 ECP91CHAB
