10.10 Push or Geared Type Control Station and Cable Parts
Figure
No.
Part Name
Parts Per
Hoist
100S
150S
200S
1
Switch Box
1
MR1IS9401
2
Switch Box Lid
1
MR1DS9411
3
Switch Box Packing
1
MR1DS9421
4
Machine Screw with Spring Washer
4
MS551010
5
Spacer
4
MS517010
6
Plate
1
MR1HS9405
7
Machine Screw with Spring Washer
4
MS554010
8
Cord Holder Support Packing
1
MS527010
9
Cord Cover
1
ER1IS9347
10
Machine Screw with Spring Washer
2
E6F151003
S
1
MR1IS5445
11
Plate Assembly
D
1
ER1IB5445
12
Machine Screw with Spring Washer
4
MS554010
13
Machine Screw with Spring Washer
4
MS555010
14
Electromagnetic Contactor
1
MGC22306A
15
Machine Screw with Spring Washer
2
MS556010
16
Machine Screw with Spring Washer
3
MS555010
Transformer
-
Primary = 208-230/460V
- Secondary = 110V
1
TRF63M601
17
Transformer
-
Primary = 575V
- Secondary = 110V
1
TRF33K601
18
Electromagnetic Contactor (DUAL
SPEED ONLY)
D
1
MGC11226A
19
Machine Screw with Spring Washer
2
J1AW24001414
20
Terminal Plate 18p
1
ECP1518AA
21
Machine Screw with Flat & Spring Washer
2
J1AW24001010
22
Machine Screw with Spring Washer
4
MS554010
23
Spring Lock Washer
4
9012711
24
Socket Bolt
4
9091272
25
Holder Cover
1
ECP5924AE
26
Cord Packing
1
ECP5924AC
27
Holder Nut
1
ECP5924AD
28
Socket Bolt
2
9093350
29
Spring Lock Washer
2
9012711
30
Cable Support Bar Complete Set
1
MR1DS1491
31 Cable Support Arm
1
MR1DS9492
32 Cable Support Bar
1
MR1DS9491
33 Wire Guide Assembly
1
MR1DS1493
34 Support Bar Holder
1
MR1DS9501
35 Spring Washer
2
9012712
36 Bolt
2
9093329
37
Cable Hanger 21 Assembly
1
MS1733010B
38
Power Supply Cable Assembly
1
MR1JS1771
39 Cord Holder Packing
1
ECP6922AA
40 Power Supply Cable 4C
1
8/4
41 Cable Support 14
1
M7HE010M1105
42
Cord Holder A Assembly
1
60704
