10.1 Housing and Motor Parts
Single Body Hoist
Double Body Hoist
Figure
No.
Part Name
Parts Per
Hoist
080S
100L
Parts Per
Hoist
100S
150S
200S
41
Name Plate OM
1
ER1BS9891
2
ER1BS9891
42
Spring Pin
1
E3S129005S
2
E3S129005S
43
Cover Suspender A
1
ER1BS9431
2
ER1BS9431
44
Cover Suspender B
1
ER1BS9432
2
ER1BS9432
45
Washer
2
ER1BS9436
4
ER1BS9436
46
Machine Screw w/ Spring
Washer
2
ES650005S
4
ES650005S
47
Packing C
1
ER1ES9117
2
ER1ES9117
48
Controller Cover Assembly
1
ER1ES1104
2
ER1ES1104
49
Socket Bolt
4
9091276
8
9091276
50
Toothed Lock Washer
4
9679711
8
9679711
S
1
80084
A1GHM1Q
Q9A3
S
2
A1GHM1QI
9A3
A1GHM1PI
9A3
A1GHM2QI
9A3
Name Plate B
D
1
80085
D
2
Name Plate B (Blank)
D
1
A1CHM20
S9A5
D
2
A1CHM20S9A5
51
Name Plate D
D
1
A1GHM1Q
S9A6
D
2
A1GHM1Q
S9A6
A1GHM1P
S9A6
A1GHM2Q
S9A6
53
Warning Label EE
1
E2D866125
2
E2D866125
54
O Ring
2
9013317
4
9013317
55
Connection Shaft
1
ER1ES9121
2
ER1ES9121
56
Plate A
1
ER1ES9123
2
ER1ES9123
57
Socket Bolt
2
9091249
4
9091249
58
Toothed Lock Washer
2
9012709
4
9012709
59
Fixing Shaft Assembly
1
ER1ES1122
2
ER1ES1122
60
O Ring
2
9013307
4
9013307
