33
10.5 Bottom Hook Parts 15 & 20 Ton
Figure
No.
Part Name
Parts Per
Hoist
150S 200S
1 Bottom Hook Complete Set 1 ER1JS1121 ER1KS1121
2
Bottom Suspension Plate B
Assembly
1 E6S5035150 E6S5035200
3 Bottom Chain Guide 2 E6S066150 E6S066150
5 Bottom Idle Sheave Assembly (X) ER1HS1052 (3) ER1HS1052 (4)
6 Bottom Shaft Assembly (X) E6S5054075 (3) E6S5054075 (4)
7 Bottom Cross Guide (X) E6S067150 (4) E6S067150 (6)
8 Bottom Collar (X) E6S065150 (4) E6S065150 (6)
9 Guide Roller (X) E6S062075 (4) E6S062075 (6)
10 Bottom Stay Bolt (X) E7S038150 (4) E7S038150 (7)
11
Bottom Suspension Plate A
Assembly
1 ER1JS5034 ER1KS5034
12 Spring Washer (X) E6S082075 (8) E6S082075 (14)
13 Nut (X) E6S081075 (8) E6S081075 (14)
14 Name Plate A 1 ER1JS9069 ER1KS9069
15 Bottom Hook Assembly 1 ER1JS2121 ER1KS2121
16 Hook Nut 1 E6S024150 E6S024200
17 Stopper Screw 1 J1TB01110016
18 Bearing Cover 1 E6S023150 E6S023200
19 Thrust Bearing 1 ES022150 ES022200
20 Bottom Yoke 1 E6S030150 E6S030200
22 Latch Kit Assembly 1 M2071150 M2071200
