10.11 Top Suspension Plate parts 8 & 10 Ton

Figure

No.

Part Name

Parts Per

Hoist

080S

Parts Per

Hoist

100L

100S

1

Top Suspension Plate Assembly

1

ER1HS1003

1

ER1IS1003

2

Top Suspension Plate B Assembly

1

ER1HS5004

1

ER1IS5004

3

Guide Roller

4

E6S062075

4

E6S062075

4

Top Stay Bolt

3

E6S007075

4

E6S007075

6

Top Idle Sheave Assembly

1

ER1HS1051

1

ER1HS1051

7

Top Suspension Plate A Assembly

1

ER1HS5003

1

ER1IS5003

8

Spring Washer

6

E6S082075

8

E6S082075

9

Nut

6

E6S081075

8

E6S081075

10

Shaft Stopper

2

ER1HS9056

3

ER1HS9056

11

Top Shaft

1

E6S053075

1

E6S053075

12

Socket Bolt

4

9091271

6

9091271

13

Spring Washer

4

9012711

6

9012711

14

Suspender Shaft

2

E6S008075

4

E6S008075

17

Connection Yoke Assembly

1

ER1HS5005

(X)

ER1HS5005 (1)

ER1IS5005 (2)

18

Chain Holder

1

ER1IL9017

19

Chain Pin

1

E6S041075

20

Snap Ring

1

9047121
