1 A11385-00 Ground Wire Assembly Kit
2 A11352-00 Cable Assembly
3 LKIT0003-00 Connection Kit (Includes Items 5 thru 8)
4 18566-05 Transient Suppressor, 10 VDC
5 LSMM0006 Rubber Bushing, Tapered
6 7296-00 Nut
7 EPS-4245 High Voltage Cable Connector
8 8521-06F Nut Retaining Screw
9 18566-11 Transient Suppressor, 150 VDC
10 78908-00 Capacitor, 1µF, 250 VAC
Item #
LEPS5001 POWER SUPPLY - PARTS LIST (Figure 18)
Part # Description Notation
3 LKIT0003-00 Connection Kit 1 2
8 78678-02 Door, PC Board Assembly 1 1
13 74300-00 Bulb, 120 VAC 2 4
16 4131-08 Fuse, 3AG, 2/10A, Motherboard 1 2
17 14684-01 Relay, 120 VAC, 3 PDT 1 2
18 LSME0083-00 Relay, 120 VAC, 3PDT 1 1
19 78674-00 Mother Control PC Board Assembly 1 1
20 78676-00 Master Control PC Board Assembly 1 1
21 LECU4013 Motor Control Board Assembly 1 1
22 41-VSO-1002 Solenoid, 120 VAC 1 1
23 77235-01 Pressure Switch 1 2
27 72771-10 For Fuse, 2.5 Amp, Time Delay, 250V, 5 X 20mm, 5 10
240 VAC Input TB7
72771-14 For Fuse, 5 Amp, Time Delay, 250V, 5 X 20mm, 5 10
120 VAC Input TB7
SSW-1064 High Voltage Cable * *
LEPS5001-02 Power Supply 0 1
Item #
RECOMMENDED SPARE PARTS LIST
Part # Description 1-4 4+
Total # of Power Supplies
* Dependent on system configuration
Voltage Master 2 - Parts Identification
44
