SPECIFICATIONS
Operating Temperature: 0°C to 45°C
Storage Temperature: -40°C to 85°C
Humidity: 85% non-condensing
CONTROL PANEL
Size: 20" H x 16" W x 8" D
(50.8cm x 40.6cm x 20.3cm)
Weight: 76 lbs. (20.4kg)
Input Pressure: 100 psi max. (6.9 bar)
POWER SUPPLY
Size: 21" Dia. x 28" H
(.53m Dia. x .71m H)
Weight: 254 lbs. (115.2 kg)
Environmental / Physical
CONTROL PANEL
AC Input: Model 78789-02 (Standard)
105-130 Volts AC
50/60 Hz, Single Phase
Fuse Protected at 5 Amps
Model 78789-04*
210-260 Volts AC
50/60 Hz, Single Phase
Fuse Protected at 2.5 Amps
* Not Listed With Factory Mutual
Electrical Aerobell 33 and REA-III automatic systems. Ad-
ditional features, described later in this manual,
include remote analog control of the high voltage
and overload setpoints. Analog output signals are
also supplied for remote monitoring of the actual
high voltage and current outputs.
AC Output: 0-120 Volts AC at 4 Amps max.
(To Power Supply)
Dry Contacts: 10A, 1/3HP, 120VAC max.
Analog 0-10 Volts DC or 4-20ma
Inputs: (Jumper Selectable)
Analog 0-10 Volts DC or 4-20ma
Outputs: (Jumper Selectable)
POWER SUPPLY
AC Input: 0-120 Volts AC at 4 Amps max.
(From Control Panel)
HV Output: 0 to negative 100kV DC
Current
Output: 1,500 microamps max. at 100kV
Analog
Outputs: 0-10 Volts DC
