Ransburg REA Automatic Applicators 77359, 76110, 77140 - Manual (Page 55)

78 Clamping Nut 76926-00
79 Valve Cap 76925-00
80 Elbow, 1/8 NPT x 3/16 T 14157-08
81 Fitting, 1/8 NPT x 3/16 T (2 Required) LSFI0025-09
82 Tubing, 3/16 O.D. (20” Required) SSP-5014
Dielectric Grease (1 oz.) LSCH0009-00
Dielectric Grease (4 oz.) 59972-00
Special Multi-Purpose Wrench 19749-00
Applicator Cover 77342-00
Rebuild Kit
(Cartridge Valve Only) 76931-00 1 2 3 4
High Voltage Probe Assy. 75156-03 1 1 2 2
Electrode LREA4001-01 1 2 3 4 Trim at assembly
Probe Holder O-Ring LSOR0007-05 2 2 4 4
Fluid Manifold O-Ring SSG-8137 2 2 4 4
Needle Shaft LREA4005-00 1 1 2 2
Fluid Cartridge Valve 76917-00 1 1 2 2
Cartridge Valve O-Ring SSG-8136 2 2 4 4
High Voltage Module 77301-01 1 1 1 1
Applicator Barrel Kit 75038-01 1 1 2 2
High Voltage Cable SSW-1064 Order Per Foot
Fluid Nozzle 4907-XX 2 2 4 4 Replace XX with 44, 45, 46,
47 or 48
Air Cap 4904-XX 2 2 4 4 Replace XX with 63, 98, or
65R
Air Cap Retaining Ring 73569-00 1 1 2 2
Disposable Applicator Covers 77342-00 1 1 2 2 Package of 5
Multi Tool Applicator Wrench 19749-00 2 2 4 4
High Voltage Test Probe Kit 76652-01 1 1 1 1 For Troubleshooting
complete assembly.
Rebuild Kit for Trigger and Dump Valves 76931-00
Kit includes:
(1) Piston Cup VA-246
(1) Needle Seal 76920-00
(1) O-Ring 7554-10
(1) Valve Spring 76928-00
(1) Needle Seat 75960-00
(1) Valve Spring 76928-00
(1) Needle 76921-00
(1) Instruction Sheet 76924-00
(1) O-Ring SSG-8136
RECOMMENDED SPARE PARTS FOR REA 9000W (Model No. 77140)
Description Part # No. of Applicators Notes
1-2 3-4 5-6 7-8
Item # Description Part #
REA 9000W SPARE PARTS IN KIT FORM (Model No. 77140)
REA 9000W WATERBORNE PARTS LIST (Model No. 77140) (Cont.)
Item # Description Part #
Ransburg
REA Automatic Applicators - Parts Identification
51 AA-99-02.5
