SPECIFICATIONS -
SOLVENTBORNE REA 900A
Electrical / Physical
Operating Voltage: 85kV DC [-] max.
Current Output: 120 microamperes max.
Weight: 84 oz. (2,100g)
Applicator Diameter: 5.50-inch (13.9cm)
Applicator Length: 14.85-inch (37.6cm)
Center Distance from Mount to:
Nozzle End 13.00-inch (32.9cm)
Center Line of
Nozzle 1.90-inch (4.8cm)
Cable Lengths: 36 ft.(std)
(Optional: 50, 75, and
100ft.)
Atomizer Assembly: 4904-65R
4907-45
HVLP 75600-01
HVLP 75601-00
Fluid Flow Rate: Variable to 1,000 cc/min.
Operating Pressure (Air Spray):
Fluid 0-100 psig (6.8 bar)
Air 0-100 psig (6.8 bar)
Consumption 16 SCFM @ 50 psig
Operating Pressure (HVLP Spray):
Fluid 0-100 psi (6.8 bar)
Air 0-100 psi (6.8 bar)
Consumption 22 SCFM @ 50 psig
(input) for 10 psig
nozzle output
Atomization Air Inlet
Size: 1/4” NPT (F) 1/2” ODT
Fan Air Inlet
Size: 1/4” NPT (F) 1/2” ODT
Fluid Inlet Size: 1/4” AN (F) 1/4” ODT
Dump Outlet Size: 1/4” AN (F) 3/8” ODT
Trigger Actuation: 1/8” NPT (F) 1/4” ODT
Dump Actuation: 1/8” NPT (F) 1/4” ODT
Shroud Purge Air: 1/8” NPT (F) 1/4” ODT
Gun Mounting Stud
Diameter: .98” - 1.00”
Mount Woodruf Key
Size: 1/4” Nominal
Paint Resistance*: .1 MΩ to ∞
NOTES
