Page 18: Rea automatic applicators - introduction
*( Ransburg Meter)
SPECIFICATIONS -
SOLVENTBORNE REA 9000R
Operating Voltage:
85kV DC [-] max.
Current Output:
120 microamperes max.
Weight:
41 oz. (1,162g)
Applicator Height:
6.5-inch (33.66cm)
Applicator Length:
13.25-inch (33.66cm)
Applicator Width:
2-inch (5.08cm)
Cable Lengths:
36-ft.
(Optional: 50, 75, and 100 ft.)
Atomizer Assembly:
4904-65R
4907-45
HVLP 75600-01
HVLP 75601-00
Fluid Flow Rate:
Variable to 1,000 cc/min.
Operating Pressure (Air Spray):
Atomizing Air
0-100 psig (6.8 bar)
Fan Air
0-100 psig (6.8 bar)
Trigger Air
40 psig min. (2.7 bar)
100 psig max. (6.8 bar)
Fluid
0-100 psig (6.8 bar)
Operating Pressure (HVLP Spray):
Atomizing Air
0-100 psig (6.8 bar)
Fan Air
0-100 psig (6.8 bar)
Trigger Air
40 psig min. (2.7 bar)
100 psig max. (6.8 bar)
Fluid
0-100 psig (6.8 bar)
Piston Air Inlet
Size:
3/16” ODT
Atomization Air Inlet
Size:
3/8” ODT
Fan Air Inlet Size:
3/8” ODT
Fluid Inlet Size:
1/4” ODT
Paint Resistance*:
.1 MΩ to ∞
Electrical / Physical
*(Ransburg Meter)
SPECIFICATIONS -
WATERBORNE REA 9000W
Operating Voltage:
70kV DC [-] max.
Current Output:
120 microamperes
max. (Classic)
Weight:
82 oz. (2,325g)
Bulkhead Diameter:
6.69-inch (16.9cm)
Max Applicator Height:
7.90-inch (20.0cm)
Applicator Length:
16.51-inch (33.0cm)
Center Distance from Mount to:
Probe End
15.23-inch (38.6cm)
Nozzle End
11.80-inch (29.9cm)
Center Line of Nozzle
1.90-inch (4.8cm)
Center Line of Probe
5.92-inch (15.0cm)
Cable Lengths:
Classic Version
100 ft. max.
(SSW-1064 HVCable)
Atomizer Assembly:
4904-65R
4907-45
HVLP 75600-01
HVLP 75601-00
Fluid Flow Rate:
Variable to 1,000 cc/min.
Operating Pressure (Air Spray):
Fluid
0-100 psi (6.8 bar)
Air
0-100 psi (6.8 bar)
Consumption
16 SCFM @ 50 psig
Operating Pressure (HVLP Spray):
Fluid
0-100 psig (6.8 bar)
Air
0-100 psig (6.8 bar)
Consumption
22 SCFM @ 50 psig
(input) for 10 psig
nozzle output
Atomization Air Inlet
Size:
3/8” NPT (F) 1/4” NPT
(F) 3/8” ODT
Fan Air InletSize:
3/8” NPT (F) 1/4” NPT
(F) 3/8” ODT
Fluid Inlet Size:
1/4” AN (F) 1/4” ODT
Dump Outlet Size:
1/4” AN(F) 3/8” ODT
Trigger Actuation:
1/4” ODT - 1/8” NPT (F)
Dump Actuation:
1/4” ODT - 1/8” NPT (F)
Probe Shroud/Knife
Air:
1/4” ODT - 1/8” NPT (F)
Shroud/Applicator
Cover Purge Air:
1/4” ODT - 1/8” NPT (F)
Applicator Mounting
Stud Diameter:
.98” - 1.00”
Mount Woodruf Key Size:
1/4” Nominal
Electrical / Physical
Ransburg
REA Automatic Applicators - Introduction
14
AA-99-02.5
