VALVE BODY SERVICE
(REA 9000W)
When service is performed on any of the body
elements, it is best to remove the barrel and high
voltage module / transformer assembly to avoid
damage to the nozzle, electrode or any of the
plastic parts.
After the disassembly of any body element:
• Clean all parts with a suitable clean solvent.
• Check all parts for damage or wear. Replace
those that are damaged or worn with new
parts.
AIR VALVE BODY
DISASSEMBLY
(REA 9000W)
1. Remove barrel assembly (see “Barrel Re-
moval for the 9000W”, previously discussed in
this section).
2. Remove high voltage module/transformer
assembly (see “Transformer Assembly Re-
place-ment, for the 9000W”, previously discussed
in this section).
3. Remove two (2) back plate screws.
TO RETURN THE SPRAY
APPLICATOR TO THE
WORK SITE
1. Attach applicator to mounting bar and secure
screws.
2. Attach the air line to applicator air fittings.
3. Attach fluid hose to fluid hose fitting.
4. Attach and secure the low/high voltage cable
to the spray applicator.
5. Turn the power, air and fluid on at the source
and return the applicator to service.
>
DO NOT overtighten low voltage cable con-
nection to spray applicator as damage to plastic
parts may occur.
C A U T I O N
!
Assembly:
1. Connect low voltage cable to control unit;
hand tighten.
2. Connect other end of low voltage cable to con-
nector assembly using a wrench on the connector
flats to tighten.
