NOZZLE AND
ELECTRODE CLEANING
OR REPLACEMENT
(REA 9000W)
C A U T I O N
!
>
NEVER bend the electrode!
Air Cap
1. Unscrew retaining ring, remove air cap from
barrel and clean using proper method or replace
it.
2. Replace air cap and tighten retaining ring back
onto the barrel.
NOTE
>
See “Atomizer Assembly Cleaning
Procedure” previously discussed in this
section.
W A R N I N G
!
>
NEVER shorten the electrode wire.
Fluid Nozzle
>
To avoid damage to the fluid nozzle, needle/
electrode, the paint pressure MUST be released
by triggering the applicator prior to removing
the tip.
>
The applicator MUST be tilted front down to
remove the air cap and/or fluid nozzle. Failure
to do so may allow paint to enter the air passag-
es, thereby reducing air flow and damaging the
applicator barrel/cascade. Applicators may be
flushed in lieu of removing nozzles. However,
they MUST be either flushed or tilted down
BEFORE removing the fluid nozzle!
>
The control unit power MUST always be off
when removing the nozzles.
C A U T I O N
!
1. Remove air cap and retaining ring from barrel
and clean or replace it.
2. With the nozzle wrench on wrench flats,
remove fluid nozzle from barrel.
3. Clean or replace fluid nozzle using appropri-
ate cleaning method.
4. Screw the cleaned or new fluid nozzle into
barrel and secure with the nozzle wrench.
5. Screw retaining ring over the air cap onto
barrel.
> Using any tool other than the Ransburg
19749-00 wrench to remove or reinstall the
fluid nozzle may distort or damage it.
> Over-tightening of plastic parts may cause
breakage.
C A U T I O N
!
