08/12 42 51300 Rev. 1
Section 6: Parts
6.1. PLATFORM AND PILLAR ASSEMBLY PARTS LIST
ITEM PART NO. DESCRIPTION
1 71622 Pillar Rod, Long
2 58933 Pillar
3 95847 Platform Cover
4 95848 Frame
5 95855 Cotter Pin
6 58937 Bearing, Platform
7 95856 Screw, Ph Hd
8 95857 Screw, Allen
9 95858 Level, Bubble
10 95859 Pin, Corner Loop
11 71623 Loop, Corner
12 71624 Bearing, Corner Loop
13 71625 Cotter Pin
10, 11 58938 Loop, Corner Assembly
12,13 58938 Loop, Corner Assembly
14 95867 Hex Nut
15 95868 Hex Head Bolt
16 95869 Wheel, 5" Diameter
17 71627 Cotter Pin
18 71629 Washer, Flat
19 71630 Axle
24 95861 Pivot, Load & Fulcrum
25 72948 Short Lever Assy
26 58939 Center Connection Assy
31 95863 Center Pivot, Long Lever
33 72947 Long Lever Assy
34 95864 Long Lever Tip Pivot
35 58934 Steelyard Rod Assy
44 71592 Acorn Nuts (2)
61 95865 Platform Locking Pin
62 95866 Cotter Pin, Platform Locking Pin
