4.2 System Component Dimensions
The specifications for all of the FEC INC. standard AFC1200 System equipment are outlined in this
Chapter to aid in determining enclosure requirements. The dimensions for the System monitor (CRT)
are based upon a current standard which is subject to variation with advancements in technology.
4.2.1 Monitor (VGA CRT)
FIG. 4-2-1 Approximate Dimensions of Monitor (VGA CRT)
The System specifications require a CRT that uses a standard VGA interface. The dimensions
of the current model can be obtained by contacting FEC INC.
An optional VGA-compatible LCD may be connected in place of the Monitor.
Chapter 4: System Setup and Wiring
Page 4-3
