Emergi-Lite Survive-All SVX Combo Series - Manual (Page 4)

SVX Series – Survive-All Combination Unit
4/4
Emergi-Lite
Tel: (888) 552-6467 ext. 547 or 255 Fax: (888) 867-1565 www.emergi-lite.com 02/08 750.1157 Rev. B
Lamps adjustment
Adjust the lamps in appropriate position. The lamp can adjusted 90
degrees horizontaly and verticaly when wall mounted. For canopy
mount, a plastic pin can be removed to increase horizontal adjustement
up to 180 degrees (See fig. 11). Lamp shouldn’t be directed on opaque
surface, closer than 3 feet.
Food processing facilities
Screw and knock-out covers (See fig. 1&2 part 2&25) are available in the
hardware kit. These covers can be installed on screws and knock-out to
avoid any food accumulation. Note: some detergent used in food pro-
cessing industry can affect durability of Polycarbonate lens.
Maintenance (All Models)
None required. If AC supply to the unit is to be disconnected for 2
months or more, the battery must be disconnected.
Figure 11
