Appendix IR7000
76
Teledyne Analytical Instruments., - Rev. 3
A-3.1 Codes for "e" Type Messages
The codes for "e" type messages are:
C ODE M ESSAGE R ETURN
AE Audible alarm Enabled? “enabled” or ”disabled”
AH Alarm High limit triggered? “alarm” or ”ok”
AL Alarm Low limit triggered? “alarm” or ”ok”
AP Auto cal Period in hours?
AS Audible alarm Sounding? “alarm” or ”ok”
CD Cal Delay?
CS what Cal Selected? (in progress) “none” or “zero” or “upscale”
CT Cal Track or hold? “track” or “hold”
DB Display Brightness “0” or “1” or “2” or “3”
DV Decimal Value (position of dp)
FS Filter Selection?
LM Linear Mode? “linear” or “nonlin” or “counts”
PL Panel Locked “locked” or “unlock”
RS chart Range Selected? “a” or “1” or “2” or “3” or “4”
RU chart Range in Use? “1” or “2” or “3” or “4”
TC Timed Cal type? “zero” or “full”
XG oXygen Cal good? “ok” or “no_zero” or “no_ups” or
“no_both
1L 1
st
(ir) Low alarm setting?
1C 1
st
(ir) Cal gas value
1G 1
st
(ir) cal Good “ok” or “no_zero” or “no_ups” or
“no_both
1I 1
st
(ir) displayed value?
1N 1
st
(ir) Name of gas? “name” (“CO=”)
1R 1
st
(ir) chart Range 1 value?
2R chart Range 2 value?
3R chart Range 3 value?
4R chart Range 4 value?
1S 1
st
(ir) Sensor raw counts
1U 1
st
(ir) Units of displayed value? “name” (“PPM”)
1X 1
st
oXygen span cal setting?
1P 1
st
(ir) oXygen value in Percent?
1D Decimal value oxygen
1H 1
st
(ir) High limit alarm setting
