NDIR Gas Analyzer Introduction 1
Teledyne Analytical Instruments., - Rev. 3 7
• Input Buttons—4 push buttons are installed on the front panel
and are used to enter data and set operational modes.
• Flowmeter—an integral flowmeter is mounted on the front
panel for monitoring the sample flow through the instrument.
• Power Switch—an off/on switch is mounted on the front panel
for powering up the instrument.
• Sample Pump Switch (IR7000P only)—this switch controls
the operation of the sample pump on portable models.
• Sample Pump Connector (IR7000P only)—a quick
disconnect nylon fitting is mounted on the front panel of
portable models for attaching the sample probe to the
instrument.
.
